8705 IntelliNetĀ® Network Control Center

The complete end-to-end network monitoring and management platform.

AES is excited to introduce the IntelliNetĀ® Network Control Center (INCC). This
software combines the capabilities of the MultiNet Receiver (MNR), including IP
control and the Network Management System (NMS), into one platform.

Now, you no longer need to rely on costly proprietary hardware. The INCC software from AES allows you to receive and send alarm signals to central station alarm automation software and monitor all facets ofyour network from a centralized dashboard.

Benefits

These are the benefits of this product.

Technical Specifications

Server Hardware (min requirements)

IntelĀ® XeonĀ® quad core microprocessor with minimum speed of 2.4 GHz, or similar specification x64 IntelĀ® compatible microprocessor

1 TB disk drive storage

8GB RAM

File System -ext4

Monitor = VGA 1024 x 768 resolution (minimum)

Operating System

Ubuntu server 20.04.4 (64 bit) *Note newer versions will not work

Database Requirements

No requirements - built-in DB will be used

Database Requirements

UL 864, Control Units and Accessories for Fire Alarm Systems

UL 2610, Commercial Premises Security Alarm Units and Systems

NYFD and CSFM Approved

Environment

Software must be installed in temperature environment maintained between 55-95ĀŗF (13-35ĀŗC)

Features

Dimensions

13.25″H x 8.5″W x 4.3″D
(24cm H x 21.5cm W x 11cm D)

WEIGHT

  1. Approx. 12.85 lbs (5.8 kilograms), with 12V 10 Ah battery
  2. Approx. 5.8 lbs (2.6 kilograms), excludes battery

Radio Frequency

Standard Frequency Range: 450-470 MHz
Contact AES for other UHF and VHF frequencies

Antenna

2.5 db Tamper resistant antenna included

Power Input

16.5V AC Class 2 transformer
Transformer not included

Backup Battery

10 Ah with 7794; 5 Ah without, UL recognized lead acid gel battery
Size based on Subscriber configuration

CURRENT CONSUMPTION

Backup Battery Power

  1. Standby = .149A
  2. Transmit = .728A
  3. Optional 7794 = .160A, Standby and Alarm
  4. Optional 7762 = .015A

ALARM SIGNAL INPUTS

  1. 8 individually programmable zones
  2. 4 x 4 Option with 4 individually programmable zones and 4 reverse polarity inputs

UL Standards

  1. UL 864 Standard for Control Units and Accessories for Fire Alarm Systems, Edition 9
  2. UL 365 Standard for Police Station Connected Burglary
  3. UL 1610 Standard for Central Station Burglary Alarm Units

Power Output

2 Watts and 5 Watts
Contact AES for other options

OPERATING TEMPERATURE

32 to 122°F (0 to 50°C)

STORAGE TEMPERATURE

14 to 140°F (-10 to 60°C)

RELATIVE HUMIDITY

0 to 93% RHC, Non-Condensing

ANNUNCIATOR

Optional 7740 Local Annunciator

ANTENNA CUT/COMMUNICATION TROUBLE OUTPUT

Form C relay; fail secure; rated for 24 VDC 1A resistive

PROGRAMMING INTERFACE

Handheld programmer

Ports

Serial Communication Port

RESET BUTTON

Located on main circuit board

ENCLOSURE MATERIAL

Steel with paint finish

ENCLOSURE COLOR

Red

VISUAL INDICATORS

LED Indicators inside enclosure
(ALM, Trouble, Tx, Rx, WA)
