Encapsulated Power Supply with Screw Terminals
Power any 2.0 AES Subscriber from the Alarm Panel
The 2425 Encapsulated Power Supply from AES enables the AC input in the alarm panel to power an AES 2.0 Subscriber. This eliminates unnecessary electrical work and the need for a dedicated power outlet to install an AES Subscriber. This product is only compatible with AES’s 2.0 Subscribers.
How to install the 2425 Encapsulated Power Supply from AES:
Dimensions 4.41” L X 2.67” W x 1.50” D
Weight 11.07 oz
Input Voltage 100~240VAC, 1.5 - 0.8A, 50/60Hz
Output Voltage 24DC
Output Current 2500mA
Max Power 60 Watts
